Lupine Alpha Lamp

Description

The Lupine Alpha is the top model from Lupine. With an enormous 7200 lumens, the Alpha offers perfect illumination and a range of almost half a kilometer. The LED bike lamp is designed for night racing use and provides optimal illumination.

• Material: Aluminium 6061-T6, Shot-peen, hard-anodized
• Weight: 225 g
• Dimensions (LxWxH): 41 x 75 x 53 mm
• Protection class: IP 68 (waterproof), IK 09 (impact resistance)
• Lens: Multi-Lens-System 22° / 18° / 180°
• Illuminant: 8 x Cree XM-L2 U4, 8x XQ-E HI
• LED board copper
• Colour temperature: 6000 K (5% tolerance)
• Microprocessor: 14-bit RISC ( 4-fold PLL )
• Clocking converter: 50KHz
• Processor clock: 32MHz
• Conductor structure: < 0.3 mm
• Temperature management: Real time
• Ambient temperature: – 30°C to 70°C
• Colours: Black
• Lux: 550 lx
• Bluetooth Technology Bluetooth 4.0

Technical data Lupine Alpha SmartCore battery

• Battery: 14.4V 6.9 Ah
• Watt hours: 99 Wh
• Weight: 430 g
• Dimensions (LxWxH): 146 x 41 x 48 mm
• Battery mounting: Velcro
• Cell type: LG MJ1186150
• Smartcore technology: Advanced battery management
• Capacity indication: 10% accurate via 5 blue LEDs
• Tail light function: integrated in capacity indicator
• Running light function: integrated in capacity display
• Balancing function: CV (constant voltage)
• Acoustic signal: 60 dB
• Microprocessor: 14-bit RISC
• PCB Reversible shutdown in case of short circuit, overvoltage, undervoltage

Scope of delivery

• Lupine Alpha Helmet Lamp Set or Lupine Alpha Lamp Set for Handlebar Mounting
